series image of 60WKS-M240/06-PB

60WKS-M240/06-PB

by Kollmorgen
$4,212.92 - $4,212.92
$4,212.92
$4,212.92 - $4,212.92
$4,212.92
In Stock, Ships 1 - 2 Days
The 60WKS-M240/06-PB is a high-quality servo amplifier crafted by Kollmorgen. This compact model from the 60WKS series is specifically meant for synchronization with SM series of brushless servo motors, promising efficient speed and torque control. It drives the motors via trapezoidal commutation while reducing current switching losses. Using PI controllers, this servo amplifier mitigates speed errors and maintains optimal current control. It accommodates a three-phase supply voltage of 60-172V and a frequency range of 50-60Hz (+/-10%), houses a ballast circuit and resistor for power control, and operates on a DC link voltage of 250V. Its peak output current reaches 15A for 5 seconds, with rated output current of 6A. LED indicators are included for diagnostics and operation signaling. Additionally, it requires an isolation transformer for operation with the mains supply, includes short circuit protection, and complies with EN60204 / EN50178 standards for operation in pollution level 2 conditions.
30 Day Warranty
Technical Specifications
  • Manufacturer: Kollmorgen
  • Product Series: 60WKS
  • Model: 60WKS-M240/06-PB
  • Integration Compatibility: Brushless Synchronous SM motors
  • Controller: Trapezoidal Commutation and PI controllers
  • Design: Compact
  • Supply Voltage: 60V to 172V
  • Frequency Range: 50Hz to 60Hz (+/-10%)
  • Characteristic Ballast circuit: Yes with 5.4kW Pulse Power
  • Integrated Ballast Resistor: Yes
  • DC Link Voltage: 250V
  • Peak Output Current, 5 seconds: 15A
  • Operational Quadrants: Four
  • Rated Output Current: 6A
  • Minimum Motor Inductance: 2.5 mH
  • Cooling Type: Natural Convection
  • LED Indicators: Yes for Diagnostics and Operation
  • Isolation Transformer Requirement: Yes with Screen Winding
  • Short Circuit Protection: Yes at Motor’s Terminals and Amplifier’s 15V Auxiliary Supply
  • IP Rating: IP 00
  • Operational Environment: Pollution Level 2 According to EN60204 / EN50178 Standards.
