Shop Indramat TBM Collection
-
Original price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00
R911246463
Bosch Rexroth IndramatAvailable, Shipping VariesThe R911246463 (TBM 1.2-40-W1/024), an auxiliary bleeder module produced by Bosch Rexroth Indramat, a reputable brand known for their superior, ind...
View full detailsOriginal price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00 -
Original price $749.97 - Original price $749.97Original price$749.97$749.97 - $749.97Current price $749.97
R911230590
Bosch Rexroth IndramatIn Stock, Ships 1 - 2 DaysThe product in question is the R911230590 (TBM 1.2-40-W1/115), an auxiliary bleeder module designed and manufactured by the internationally recogni...
View full detailsOriginal price $749.97 - Original price $749.97Original price$749.97$749.97 - $749.97Current price $749.97 -
Original price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a Quote
R911714731
Bosch Rexroth IndramatThe product, R911714731 (TBM 1.1-20-W1/115), is a bleeder module designed by Bosch Rexroth Indramat, marking their initial venture into the TBM ser...
View full detailsOriginal price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a Quote -
Original price $2,065.33 - Original price $2,065.33Original price$2,065.33$2,065.33 - $2,065.33Current price $2,065.33
R911005692
Bosch Rexroth IndramatIn Stock, Ships TodayThe R911005692 (TBM 1.1-20-W1/220), a bleeder module produced by Bosch Rexroth Indramat, forms part of their TBM series. This module safeguards bot...
View full detailsOriginal price $2,065.33 - Original price $2,065.33Original price$2,065.33$2,065.33 - $2,065.33Current price $2,065.33 -
Original price $2,065.33 - Original price $2,065.33Original price$2,065.33$2,065.33 - $2,065.33Current price $2,065.33
TBM 1.1-20-W1/220
Bosch Rexroth IndramatIn Stock, Ships TodayThe TBM 1.1-20-W1/220 is a bleeder module manufactured by Bosch Rexroth Indramat, part of the TBM series. This module serves a key safety function ...
View full detailsOriginal price $2,065.33 - Original price $2,065.33Original price$2,065.33$2,065.33 - $2,065.33Current price $2,065.33
The TBM 1.2 additional bleeder module can be installed to increase continuous and peak regenerated power. The following power ratings can be achieved by combining the TVM 2.4 and the TBM 1.2.
Continuous bleeder power (continuous regenerated power) | Peak bleeder power (peak regenerated power) | Maximum regenerated power |
---|---|---|
2.25 kW | 50 kW | 114 kWs |
Indramat TBM Dimensions
- Overall height of the unit: 373 mm
- Total width: 208 mm
- Depth from the mounting surface: 390 mm
- Minimum clearance at the top for cooling air outlet: 80 mm minimum
- Minimum clearance at the bottom for cooling air inlet: 80 mm minimum
- Distance between mounting holes (vertical): 355 mm
- Thickness of the safety guard: 7 mm
- Width of the module without the safety guard: 105 mm
- Distance from the mounting surface to the power connections (X15/L+, L-): 60 mm
- Distance from the bottom of the unit to the power connections (X15/L+, L-): 310 mm
Connection points specifications:
- X15/L+, L-: Power connections, max. 6 mm²
- X15/E: Control connections, max. 2.5 mm²
- X16: Blower supply DC 24V, max. 2.5 mm²
TBM Technical Data
PDC (kW) | PKB-3 (kW) | PKB-03 (kW) | PBD (kW) | PBM (kW) | Wmax (kWs) | Pm (kW) | PmKB-03 (kW) | Mains supply module | Additional bleeder | Transformer |
---|---|---|---|---|---|---|---|---|---|---|
2.4 | 5.5 | 11 | 0.45 / 2.25 | 10 | 14 / 114 | 1.3 | 6.1 | TVM 2.4-050-220/300-W1-.../+ accessories | TBM 1.2-40-W1-024 | 2.5 KVA |
3.8 | 10 | 20 | 0.45 / 2.25 | 10 | 14 / 114 | 2.1 | 11.1 | TBM 1.2-40-W1-024 | TBM 1.2-40-W1-024 | 4 KVA |
4.8 | 14 | 28 | 0.45 / 2.25 | 10 | 14 / 114 | 2.6 | 15.6 | TBM 1.2-40-W1-024 | TBM 1.2-40-W1-024 | 5 KVA |
- PDC: Continuous D.C. bus power
- PKB-3: D.C. bus short-time power for 3s (accelerating main drives)
- PKB-03: D.C. bus peak power for 0.3s (accelerating servo drives)
- PBD: Continuous bleeder power
- PBM: Peak bleeder power
- Wmax: Maximum regenerated energy
- Pm: Continuous mechanical power
- PmKB-03: Peak mechanical power for 0.3s (accelerating servo drives)
