Shop POWERPAC N Motors
-
Original price $1,860.00 - Original price $1,860.00Original price$1,860.00$1,860.00 - $1,860.00Current price $1,860.00N31HCLK-LNK-NS-00
Pacific ScientificThe N31HCLK-LNK-NS-00 by Pacific Scientific is a NEMA 34 compact stepper motor known for its exceptional torque output in its size category, featur...
View full detailsOriginal price $1,860.00 - Original price $1,860.00Original price$1,860.00$1,860.00 - $1,860.00Current price $1,860.00 -
Original price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00N33HRHJ-LDK-NS-00
Pacific ScientificCrafted by Pacific Scientific, the N33HRHJ-LDK-NS-00 is a hybrid motor distinguished by its large-diameter rotor and shaft, and a unique rotor desi...
View full detailsOriginal price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00 -
Original price $1,916.97 - Original price $1,916.97Original price$1,916.97$1,916.97 - $1,916.97Current price $1,916.97N33HCHJ-LNK-NS-00
Pacific ScientificThe N33HCHJ-LNK-NS-00 is a hybrid step motor produced by Pacific Scientific under their POWERPAC brand. It is compatible with a variety of drivers ...
View full detailsOriginal price $1,916.97 - Original price $1,916.97Original price$1,916.97$1,916.97 - $1,916.97Current price $1,916.97 -
Original price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a QuoteN31HRLJ-LNK-NS-01
Pacific ScientificThe N31HRLJ-LNK-NS-01 is a hybrid step motor manufactured by Pacific Scientific. Measuring 3.38 inches square, this motor is distinguished by its h...
View full detailsOriginal price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a Quote -
Original price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a QuoteN31HRHJ-LKN-NS-01
Pacific ScientificThe N31HRHJ-LKN-NS-01 is an industrially efficient two-phase hybrid stepper motor produced by Pacific Scientific, renown for creating high-quality ...
View full detailsOriginal price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a Quote
POWERPAC N Motors
POWERPAC N Motors offer a range of features tailored for efficient performance in industrial applications. Available in NEMA 34 and NEMA 42 sizes, these 2-phase hybrid stepper motors boast an 8-shaft design with straight keyways and a full step angle of 1.8°, ensuring precise movement. Their optimized magnetic design enhances overall performance, while options for IP 44 or IP 65 protection, along with a long-life steel bearing bore in the front bell, ensure durability in various environments. Additionally, their housing design is optimized for effective cooling, further enhancing their reliability and longevity.
Type Code
- Series Special Sequence
- P - Standard (Powermax) 00 - Standard motor, no shaft seal
- M - Sigmax® version (Powermax) 01 - Standard motor with shaft seal (Powerpac only)
- N - Standard (Powerpac) xx - Numbers assigned for special motors (upon request)
- K - Sigmax® version (Powerpac)
- Encoder Options
- Size NS - No feedback
- 2 - NEMA 23 (57.15 mm Ø) (Powermax only) xx - Several encoders available (upon request)
- 3 - NEMA 34 (96.52 mm Ø) (Powerpac only) M1 - Encoder mounting provision (Powermax only)
- 4 - NEMA 42 (109.85 mm Ø) (Powerpac only) M2 - Encoder mounting provision (Powerpac only)
- SS - Special (upon request)
- Number of Rotor Stacks
- H - 1/2 stack (Powermax only)
- 1 - 1 stack N - Smooth (Powermax only)
- 2 - 2 stack F - Flat
- 3 - 3 stack (Powerpac only) K - Straight key (Powerpac only)
- 4 - 4 stack (Powerpac only) S - Special (upon request)
- Mounting Configuration Shaft Configuration
- N - NEMA (Powermax only) N - Single
- H - Heavy Duty NEMA (Powerpac only) D - Double (R and C construction only)
- S - Special (upon request) E - Double ended for encoder
- S - Special (upon request)
- Construction/Hookup Rotor Types
- R - Regular
- C - System MS connector (Powerpac only) L - Laminated
- L - Splashproof/to terminal board via conduit connector: J - Low inertia (Powermax only, n/a for 1/2 stack)
- 1/2" NPS pipe thread (Powerpac only)
- M - Splashproof/to terminal board via conduit connector: metric PG11 pipe thread (Powerpac only)
- S - Special (upon request)
- Winding/Leads
- x - Receptacle (Powermax only) - order cable separately
- F - 8 lead (n/a C construction)
- L - 4 lead series
- H - 4 lead parallel
- E - 6 lead (n/a C construction) (Powerpac only)
Technical Data
| Motor Data | H | J | K | L | ||
|---|---|---|---|---|---|---|
| Motor Data | Holding torque (bipolar/parallel 2 phases on) | MH Nm | 4,5 | 4,5 | 4,7 | 4,6 |
| Rated current per winding (bipolar/parallel) | I A | 2,8 | 5,5 | 6,6 | 8,6 | |
| Technical Data | H | J | K | L | ||
| Full steps per revolution | 200 | 200 | 200 | 200 | ||
| Step angle | ° | 1,8 | 1,8 | 1,8 | 1,8 | |
| Angular accuracy | % | 3 | 3 | 3 | 3 | |
| Phases | 2 | 2 | 2 | 2 | ||
| Winding resistance | Rph Ω | 3,1 | 0,84 | 0,58 | 0,36 | |
| Winding inductance | Lph mH | 12,5 | 3,5 | 2,6 | 1,14 | |
| Detent torque | Mp Nm | 0,13 | 0,13 | 0,13 | 0,13 | |
| Insulation class | B | B | B | B | ||
| Insulation inductance | 100MΩ @ 500VDC | 100MΩ @ 500VDC | 100MΩ @ 500VDC | 100MΩ @ 500VDC | ||
| Dielectricity test | 500VDC 1min | 500VDC 1min | 500VDC 1min | 500VDC 1min | ||
Ambient Conditions
POWERPAC N motors are designed to operate under specific ambient conditions to ensure optimal performance and longevity. These conditions typically include a temperature range between -20°C to 40°C (-4°F to 104°F), with humidity levels below 90% RH (non-condensing). Additionally, the motors are engineered to withstand altitudes up to 1000 meters above sea level. These ambient conditions are crucial for maintaining the motor's efficiency, preventing overheating, and ensuring reliability in various operational environments.
