Indramat MLP

Indramat MLP Motors

The IndraDyn L motor's primary part is designated as MLP, a term that signifies its critical role in the motor's function. The motor size is determined by the width of the active magnet in the secondary part of the motor, which also corresponds to various power ranges offered by the motor. Motor lengths within a given series increase in size and are differentiated by alphabetical ID letters, such as A, B, or C, which represent frame lengths. Additionally, the winding code numbers provide an indication of the maximum speed that the motor can achieve, expressed in meters per minute (F_max). All primary parts of IndraDyn L motors are equipped with liquid cooling systems for operation, making liquid cooling the sole cooling option available for these motors, ensuring efficient heat dissipation during their use.

MLP Type Code Breakdown

The MLP Motors are available in different sizes (040, 070, 100, 140, 200, 300). The type codes for several of these variations can be found below.

MLP040


- Product:
- MLP
- Motor size:
- 040 = 040
- Motor length:
- Lengths = A, B
- Windings code:
- MLP040A. = 0300
- MLP040B. = 0150, 0250, 0300
- Cooling mode:
- Liquid cooling = F
- Encapsulation:
- Standard encapsulation = S
- Thermo-encapsulation = T
- Motor encoder:
- Without encoder = N0
- Electrical connection:
- Wire conducted through front of primary part = CN
- Other design:
- None = NNNN

MLP070:


- Product:
- MLP
- Motor Frame Size:
- 070 = 070
- Motor Frame Lengths:
- Frame lengths = A, B, C
- Winding Designation:
- MLP070A = 0150, 0220, 0300
- MLP070B = 0100, 0120, 0150, 0250, 0300
- MLP070C = 0030, 0120, 0150, 0240, 0300
- Cooling:
- Liquid cooling = F
- Encapsulation:
- Standard encapsulation = S
- Thermal encapsulation = T
- Motor Encoder:
- Without encoder = N0
- Electrical Connection:
- Cable lead out from front side of the primary part = CN
- Other Design:
- None = NNNN

MLP100


- Product:

- MLP
- Motor Frame Size:
- 100 = 100
- Motor Frame Length:
- Frame Lengths = A, B, C
- Winding Designation:
- MLP100A = 0090, 0120, 0150, 0190
- MLP100B = 0030, 0120, 0250
- MLP100C = 0090, 0120, 0190
- Cooling:
- Liquid Cooling = F
- Encapsulation:
- Standard encapsulation = S
- Thermal encapsulation = T
- Motor Encoder:
- Without encoder = N0
- Electrical Connection:
- Cable lead out on the front side of the primary part = CN
- Other Design:
- None = NNNN

Technical Data

Below is an example of the technical specs from a variety of the MLP motor subseries. For the subseries not listed here, please refer to the official documentation.

MLP040

Parameter Symbol Unit 0300 0150 0250 0300
Maximum force Fmax N 800.0 1150.0
Continuous nominal force FN N 250.0 370.0
Maximum current Imax(rms) A 18.0 18.7 28.3 36.9
Rated current IN A 3.8 3.9 5.6 6.3
Maximum velocity at Fmax VFmax m/min 300 150 250 300
Nominal velocity VN m/min 500 300 400 500

MLP070

Parameter Symbol Unit 0300 0150 0250 0300
Maximum force Fmax N 800.0 1150.0
Continuous nominal force FN N 250.0 370.0
Maximum current Imax(rms) A 18.0 18.7 28.3 36.9
Rated current IN A 3.8 3.9 5.6 6.3
Maximum velocity at Fmax VFmax m/min 300 150 250 300
Nominal velocity VN m/min 500 300 400 500

MLP200

Parameter Symbol Unit 0090 0120 0040 0120
Maximum force Fmax N 7,450.0 10,900.0
Continuous nominal force FN N 2,415.0 3,465.0
Maximum current Imax(rms) A 69.6 81.3 74.2 128.6
Rated current IN A 12.9 14.8 13.8 21.8
Maximum velocity at Fmax VFmax m/min 90 120 40 120
Nominal velocity VN m/min 170 190 100 190

Ambient Conditions

The MLP motors should be used within the ambient conditions specified below
- Low air temperature: +5°C
- High air temperature: +40°C
- Low relative air humidity: 5%
- High relative air humidity: 95%
- Low absolute air humidity: 1 g/m³
- High absolute air humidity: 29 g/m³
- Temperature change rate: 0.5°C/min
