Shop POWERMAX II P Motors
-
Original price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00
P21NSXC-LSS-NS-14
Pacific ScientificIn Stock, Ships 3 - 5 DaysThe P21NSXC-LSS-NS-14 motors, produced by Pacific Scientific, are a dependable solution for a broad range of motion applications, offering both sma...
View full detailsOriginal price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00 -
Original price $2,685.17 - Original price $2,685.17Original price$2,685.17$2,685.17 - $2,685.17Current price $2,685.17
P22NRXA-LSF-NS-02
Pacific ScientificIn Stock, Ships 1 - 2 DaysThe Pacific Scientific's Powermax II series P22NRXA-LSF-NS-02 is a NEMA 23 size hybrid stepper motor that provides impressive performance. The stan...
View full detailsOriginal price $2,685.17 - Original price $2,685.17Original price$2,685.17$2,685.17 - $2,685.17Current price $2,685.17 -
Original price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a Quote
P22NSXA-LDN-NS-02
Pacific ScientificThe P22NSXA-LDN-NS-02, a product of Pacific Scientific, is a compact yet powerful stepper motor which leads its class in torque-to-frame size ratio...
View full detailsOriginal price $0.00 - Original price $0.00Original priceRequest a Quote$0.00 - $0.00Current price Request a Quote -
Original price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00
P22NSXB-LNN-NS-05
Pacific ScientificAvailable, Shipping VariesThe P22NSXB-LNN-NS-05, manufactured by Pacific Scientific, is a high-performance NEMA 23 stepper motor used primarily for automation purposes. Desp...
View full detailsOriginal price $1,200.00 - Original price $1,200.00Original price$1,200.00$1,200.00 - $1,200.00Current price $1,200.00 -
Original price $771.96 - Original price $771.96Original price$771.96$771.96 - $771.96Current price $771.96
P22NRXA-LNN-NS-00
Pacific ScientificIn Stock, Ships 1 - 2 DaysThe Pacific Scientific P22NRXA-LNN-NS-00 is a double rotor stack stepper motor designed for efficiency, durability, and cost-effectiveness. With be...
View full detailsOriginal price $771.96 - Original price $771.96Original price$771.96$771.96 - $771.96Current price $771.96
POWERMAX II P Motors
The POWERMAX II M Motors boast unique features that set them apart in the market. Utilizing patented Sigmax® technology, these motors redirect magnetic flux to enhance torque production while minimizing leakage. Their rotor construction is tailored to specific needs: the "L" rotor design in the POWERMAX II M and P Series features laminated construction for high-speed efficiency, whereas the "J" rotor design offers low mass and low inertia, enabling fast start/stop and high acceleration capabilities.
Technical Specifications
- Rotor Construction:
- POWERMAX II M and P Series with "L" rotor: Laminated (high-speed efficiency)
- POWERMAX II M and P Series with "J" rotor: Low mass/low inertia (fast start/stop, high acceleration)
- Windings:
- A, B, C, D, E, F, G: Standard winding to match any application
- Phases: 2
- Full Steps per Revolution: 200
- Full Step Angle: 1.8°
- Angular Accuracy:
- POWERMAX II M and M "J": ±1.5% of one step, no load, non-cumulative
- POWERMAX II P and P "J": ±3% of one step, no load, non-cumulative
- Operating Temperature: -20 to 40°C
- Insulation: NEMA Class B, 130°C
- Insulation Resistance: 100 Megohms @500V dc and 25°C
- Shaft Load Ratings:
- Max. Radial Load (at center of std. shaft extension): 20 lb.
- Max. Axial Load (on front shaft extension toward motor): 13 lb.
Technical Data
P2HNRXx-LNN-NS-00* | ||||
---|---|---|---|---|
F | C | H | ||
Motor Data | Holding torque (bipolar/parallel 2 phases on) | 0.42 Nm | 0.43 Nm | 0.42 Nm |
Rated current per winding (bipolar/parallel) | 1.6 A | 2.5 A | 5.2 A | |
Technical Data | Full step | 200 per revolution | ||
Step angle | 1.8° | |||
Angular accuracy | 3% |
Data Continued
P21NRXx-LNN-NS-00* | |||||
---|---|---|---|---|---|
D | C | B | A | ||
Motor Data | Holding torque (bipolar/parallel 2 phases on) | 0.77 Nm | 0.82 Nm | 0.79 Nm | 0.81 Nm |
Rated current per winding (bipolar/parallel) | 1.5 A | 3.5 A | 4.6 A | 5.6 A | |
Technical Data | Full step | 200 per resolution | |||
Step angle | 1.8° | ||||
Angular accuracy | 3% | ||||
Phases | 2 | ||||
Winding resistance | 5.22 Ω | 1.06 Ω | 0.64 Ω | 0.46 Ω | |
Winding inductivity | 10.3 mH | 2.3 mH | 1.1 mH | 0.8 mH |
Ambient Conditions
The Pacific Scientific POWERMAX II P series stepper motors are designed to operate within a range of ambient temperature conditions, specifically from -20°C up to +40°C. The maximum surface temperature the motor can safely reach is 95°C, allowing for operation under high-load conditions without overheating. In terms of protection, the motors are rated at IP 23 S.
