The IndraControl L10 is a compact and versatile industrial controller from Bosch Rexroth, designed to meet the demands of modern automation tasks. Featuring a scalable and flexible architecture, it allows for easy integration into various industrial environments. The controller is equipped with powerful processing capabilities, making it suitable for applications ranging from simple control tasks to complex automation processes. Its robust design ensures reliable operation even in harsh industrial conditions. Additionally, the IndraControl L10 offers user-friendly interfaces and supports a range of communication protocols, enabling seamless connectivity and efficient data exchange with other devices and systems. This makes it an ideal choice for manufacturers looking to optimize their automation solutions and improve operational efficiency.
The Bosch Rexroth IndraControl L10 is a modular, scalable, and compact control system designed for PLC applications. It features a significant amount of memory and fast processing capabilities, making it suitable for a range of industrial applications. Key specifications include:
1. Memory and Processing Speed: The IndraControl L10 is equipped with 1MB of program memory, 2MB of data memory, and 32kB of residual memory. Its processing time is impressive, at 150 microseconds for 1000 instruction list commands. This level of memory and processing speed makes it apt for small to medium PLC applications in factory automation.
2. Hardware and Interfaces: The control unit combines the benefits of a compact control with a standardized I/O system based on terminal technology. It includes an Ethernet interface, along with onboard interfaces featuring 8 fast inputs and 4 fast outputs. The device's I/O units can be easily extended by the Rexroth Inline I/O system, simply by mounting the components side by side.
3. Additional Features: The IndraControl L10 offers a full megabyte of program storage space and includes an Ethernet port for remote access or SCADA functionality. It has a scan rate approximately 20 times faster than comparable PLCs on the market. The control unit also allows for expandability of up to 256 I/O, suitable for running complex machines without needing multiple PLCs. It includes reusable code, a feature often found in larger PLCs, which helps in saving memory space and improving scan time.
Overall, the Bosch Rexroth IndraControl L10 stands out for its scalable hardware, fast processing, substantial memory, and flexible connectivity options, making it a reliable and efficient choice for various industrial automation tasks.
- Product Main Unit: CM
- Housing Design: Inline (L)
- Line: ST40 (10)
- Design: 1
- Communication Interface:
- Interface 1: Not equipped (N)
- Interface 2: Not equipped (N)
- System Configuration:
- DRAM: 32 MB (2)
- NvRAM: 32 kB (1)
- SRAM: None (0)
- Blower: Without (N)
- Digital Inputs/Outputs: 8 inputs / 4 outputs (B)
- Additional Design: None (NNNN)
- Firmware: Without firmware (NW)
