series image of AX5106-0000-0200

AX5106-0000-0200

by Beckhoff
$3,294.75 - $3,294.75
$3,294.75
$3,294.75 - $3,294.75
$3,294.75
Available, Shipping Varies
The AX5106-0000-0200 is a three-phase servo drive from Beckhoff's AX5000 series, designed for asynchronous and synchronous motors, facilitating speed, position, and torque control. This unit provides a rated output current of 6A, minimum channel current of 1A with full current resolution and a maximum output current of 13A. Noted for its supply voltage of 3 x 100 … 480VAC and maximum DC link voltage of 875VDC, it offers an 85W power dissipation, with a maximum continuous braking power of 150W and maximum braking power of 14kW. Weighing 5kg and measuring 274 x 92 x 232mm, it is equipped with advanced features to ensure optimal cooling, DC-link, and supply connection. This servo drive, compatible only with an EtherCAT system bus, can be connected to varying types and sizes of motors seamlessly. For optimal functioning, ensure vertical installation in a control cabinet with sufficient ventilation. Compliant with UL safety standards, it supports advanced technology installation without repeated re-certifications.
30 Day Warranty
Technical Specifications
  • Producer: Beckhoff Company
  • Product Type: Three-phase Servo Drive
  • Model: AX5106-0000-0200
  • Control Purpose: Speed, position, and torque control for asynchronous and synchronous motors
  • Rated Output Current: 6A
  • Minimum Channel Current: 1A
  • Maximum Output Current: 13A
  • Maximum DC Link Voltage: 875VDC
  • Rated Supply Voltage: 3 x 100 … 480VAC
  • Power Dissipation: 85W
  • Continuous Braking Power: 150W
  • Maximum Braking Power: 14kW
  • Weight: 5kg
  • Dimensions: 274mm(H) x 92mm(W) x 232mm(D)
  • Cooling Concept: Optimized cooling concept
  • AX-Bridge: Quick connection of power supply, control voltage, and DC-Link systems
  • Safety Functions: Optional TwinSAFE and restart lock
  • System Bus: EtherCAT
  • Motor Connectability: Can connect with torque, synchronous, linear, and asynchronous motors without additional measures
  • Cycle Time: Short
  • Functionality: Achieve rapid and dynamic positioning tasks
  • Installation Reminder: Ensure vertical installation and adequate ventilation for cooling
  • Certification: UL certified
