product Main (Front Left) image of DKR02.1-W200N-B

DKR02.1-W200N-B

by Bosch Rexroth Indramat
Request a quote
The Bosch Rexroth Indramat's DKR02.1-W200N-B is a drive controller part of the DKR product line, engineered to control motors from 1MB spindle motor, LSA / LAF linear motor and 2AD / ADF spindle motor series. This device functions by direct connection to AC mains ranging from 400 to 480 Volts AC (three-phase), supports motor feedback through integrated digital servo and resolver, and possesses a built-in blower for cooling. Rated at 200 Amps, it delivers an uninterrupted current rating between 95-120 Amps at 4-8 kilohertz, whilst requiring 230 Volts control voltage input at 50-60 Hertz. The DKR02.1-W200N-B has a continuous power rating of 37-47 kilowatts at 4-8 kilohertz, while regenerating a peak power of 55 kilowatts. The controller, weighing around 104 kg, adheres to IP 20 protection category, thus ensuring workplace safety. Installation should be ventured by qualified personnel only due to its technical specifications.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Line: DKR
  • Product Type: Drive Controller
  • Compatibility: 1MB spindle motor, LSA / LAF linear motor, 2AD / ADF spindle motor series
  • Voltage Connection: 400 to 480 Volts AC, three phase
  • Brake Resistor: Can be ordered with integrated brake resistor
  • Output: 200 Amps
  • Cooling System: Built-in blower
  • Bleeder: Not included
  • Continuous Current Rating: 120 Amps at 4 kilohertz, 95Amps at 8 kilohertz
  • Motor Feedback: Through integrated digital servo and resolver
  • Control Voltage Input: 230 Volts at 50 to 60 Hertz
  • Control Voltage Power Requirement: 200 VA
  • Continuous Power Rating: 47 kilowatts at 4 kilohertz, 37 kilowatts at 8 kilohertz
  • Regenerated Power Ratings: Continuous 37 kilowatts, Peak 55 kilowatts
  • Heat Dissipation: 1600 Watts
  • Weight: Controller 104 kilograms, Accessories kit 1.7 kilograms
  • Protection Category: IP 20 as per EN 60529
  • Ambient Conditions: 0 to 1000 meters altitude, 5 to 45 degrees Celsius temperature
  • Dimensions: 1000 x 440 x 290 millimeters
  • Spacing: 80 millimeters recommended above and below
  • Installation: By qualified personnel only.
