series image of MHD093C-035-NG0-RA

MHD093C-035-NG0-RA

by Bosch Rexroth Indramat
$29,006.45 - $29,006.45
$29,006.45
$29,006.45 - $29,006.45
$29,006.45
In Stock, Ships Today
The MHD093C-035-NG0-RA, a sophisticated industrial electric motor, is a product of Bosch Rexroth Indramat. It is designed to serve as a reliable servo motor or main rotary in industrial servo systems. Coupled with Rexroth drive controllers, this motor constitutes an economical automation system that can support a plethora of complex industrial machinery such as robotic applications, machine tools, handling machines, and food production machinery. With a housing designed to comply with the IP65 protection class, the motor is safeguarded against damage from liquid contact and chemical interference including hydraulic oils, lyes, dilute alkalis and acids. The motor operates quietly and efficiently with high reliability, and can perform continuous start-stop operations. With a normal speed of 3000 RPM, it can reach up to 4500 RPM at maximum input. Adhering to insulation class F, the motor can self-regulate its internals via natural convection without complex temperature regulation mechanisms. Operational efficiency is maintained at 95 percent under normal conditions.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Name: MHD093C-035-NG0-RA
  • Role: Servo Motor/Rotary Main
  • Housing Design: IP65 Protection Class
  • Housing Material: Black Prime Paint
  • Motor Type: Brushless
  • Noise Level: Reduced
  • Reliability: High
  • Commutation Type: Electronic
  • Rated Rotational Speed: 3000 Revolutions Per Minute
  • Max Rotational Speed: 4500 Revolutions Per Minute at 32.4 Amperes
  • Insulation Class: Class F
  • Temperature Regulation: Natural Convection
  • Max Ambient Temperature: 45 Degrees Celsius
  • Max Installation Height: 1000 Meters Above Sea Level
  • Operational Efficiency: Up to 95% Under Normal Conditions.
