077F8761
by Danfoss
Original price
$446.10
-
Original price
$446.10
Original price
$446.10
$446.10
-
$446.10
Current price
$446.10
The 077F8761 cable assembly is supplied by Danfoss as part of the Danfoss Cables and Accessories series. It is a short sensor lead built for industrial control panels where temperature feedback from an embedded NTC element must reach a drive, controller, or monitoring relay. By combining a predefined conductor set with a molded connector, the assembly reduces wiring time and removes crimp-related variability in repetitive automation builds.
At a total length of 1.5 m, the cable can span between a sensor location and a nearby terminal block without excess slack that could crowd narrow cabinets. The integrated RAST2.5 Edge connector provides keyed insertion into matching appliance sockets, eliminating wiring mistakes and supporting automated board insertion processes. Inside the housing are 3 pcs conductors, giving separate paths for the sensing element and reference signals. The sensing core is an NTC resistor, so the electrical resistance drops as temperature rises, allowing straightforward analog interpretation by common drive and HVAC controllers. Being part of the Danfoss Cables and Accessories series ensures dimensional consistency with other prefabricated harnesses delivered for the same product families.
Its mass characteristics assist in inventory and transport planning. The net assembly weight is only 0.044 kg, and protective packaging raises the gross figure to 0.047 kg, keeping the unit within standard low-weight parcel categories. A packed volume of 0.197 L means multiple pieces can be stored in small bins or dispatched together without exceeding shelf constraints. Delivered by Danfoss, the cable complies with the company’s usual material and workmanship standards, letting machine builders integrate temperature sensing lines with minimal onsite preparation and predictable mechanical strain on terminated boards.
