DBL4N00950-013M000000000-0047

The DBL4N00950-013M000000000-0047 synchronous servomotor from Kollmorgen belongs to the renowned DBL Synchronous Servomotors series, engineered for high-performance motion control in industrial automation. This robust motor delivers a Rated Power of 2.51 kW at 400 V and 2.94 kW at 480 V, with a flexible Mains Voltage Range of 230–480 VAC to suit diverse power environments. Operating at a Rated Speed of 3000 min⁻¹ at 400 V (3600 min⁻¹ at 480 V), it provides dynamic response and precision. With a body mass of approximately Weight 10.5 kg, it balances structural rigidity and compactness for seamless machine integration. Its series pedigree underscores consistent quality, reliability, and serviceability in demanding settings.

Technical specifications underscore its electrical and mechanical prowess. The motor supports a continuous Rated Current of 6 A RMS at 400 V (5.03 A RMS at 480 V) and a Peak Current of 38.3 A for brief high-torque demands. It generates a Rated Torque of 8.5 Nm (400 V) or 7.8 Nm (480 V) and a Standstill Torque of 9.5 Nm, backed by a Standstill Current of 6.4 A RMS. The Torque Constant of 1.49 Nm/A and the Voltage Constant of 90 mV/min⁻¹ ensure efficient energy conversion with precise control. Winding characteristics include a Winding Resistance of 1.65 Ohm and Winding Inductance of 11.7 mH, optimized for fast current loops.

Operational reliability is reinforced by a Rotor Moment Of Inertia of 6.1 kg·cm², providing excellent dynamic response and low settling times. The motor’s Thermal Time Constant of 68 minutes allows sustained operation under thermal stress, while its rugged build and optimized cooling paths maintain stable performance. Its high torque-to-inertia ratio ensures smooth acceleration and deceleration, minimizing overshoot in coordinated motion tasks. Maintenance intervals benefit from the series’ proven design, and the robust winding insulation delivers long service life even under repetitive peak loads.

Integration into advanced automation systems is straightforward, as the motor interfaces seamlessly with standard servo drives and controllers. Its broad voltage compatibility and standardized flange dimensions simplify retrofit and new-machine applications. Typical applications include CNC machining, semiconductor processing, automated inspection equipment, and robotic workcells where precision, speed, and reliability are paramount. The versatile DBL4N00950-013M000000000-0047 servomotor is ideal for engineers seeking a dependable solution in high-throughput industrial environments.
