Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Accuracy (resolver Option)
± 135 arc seconds
Axial Loading Capacity
12,700 lbs
Continuous Torque (40°c)
34.6 N-m
Dynamic Compliance Tolerance
Runout 0.13 mm relative to Datum C
Housing Diameter
330 mm
Maximum Dynamic Axial Load
11,700 lbs
Maximum Operating Speed
300 RPM
Moment Loading Capacity
472 lb-ft
o' Ring Groove Dimension
3.46-3.60 mm depth, 1.88-2.03 mm width
Peak Torque
95 lb-ft
Repeatability
± 0.62 arc seconds
Resolution (sine Encoder)
2,097,152 counts/rev
Rotor Inertia
0.0511 lb-ft-sec²
Static Friction Adder For Sealed Units
2.6 lb-ft
Weight
69.5 lb
