series image of R911260340

R911260340

by Bosch Rexroth Indramat
$3,561.75 - $3,561.75
$3,561.75
$3,561.75 - $3,561.75
$3,561.75
Available, Shipping Varies
The R911260340 (DDS02.1-W015-R) is a top-tier basic drive controller developed by Bosch Rexroth Indramat. Part of the DDS range, this modular controller is optimized for AC servo and main drive connectivity, leading to an affordable and practical drive package for varied industrial applications such as machine tooling, robotics, and handling machines. Paired with LAR, MKD, or MDD motors, it offers formidable drive proficiency. Presented as a comprehensive unit, the R911260340 (DDS02.1-W015-R) includes a software module, firmware module, and pertinent plugin cards in addition to the main drive - all tailored to the intended operational task. The controller can be connected to a DC 24V regulated voltage supply unit. Embellished with a resolver motor feedback along with a cooling system based on cold technology, the R911260340 (DDS02.1-W015-R) has a 15A rated current. Its software module is portable, housing the customizable drive parameters and firmware. The firmware can be upgraded separately. The unit operates with a 300v DC bus voltage, allowing a 15A peak and continuous current. Its IP 20 protection categorization necessitates a dust and moisture-free enclosure that meets IP 10 protection standard. It maintains an optimum operating temperature between 0 to 45 degrees and is intended only for industrial applications.
30 Day Warranty
Technical Specifications
  • Software Module: Transferable
  • Bus Voltage: 300V +/-15% DC
  • Supply Unit Connection: DC 24V
  • Motor Feedback: Resolver
  • Components: Software module, Firmware module, Plugin cards, Main drive unit
