S image of digifas 7204-LINK

digifas 7204-LINK

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The Kollmorgen digifas 7204-LINK is a state-of-the-art digital servo amplifier designed for efficient motor control, ideally suited for 6SM servo motors. The product package includes a digifas 7200 series servo amplifier, an operator software diskette, two ring cores, and a user-friendly manual. The unit operates optimally at an ambient temperature between -25 and 55 degrees Celsius. Nevertheless, for periods of transport, the device can withstand temperatures up to 70 degrees Celsius. To ensure the amplifier's longevity, it is essential to re-form the capacitors if stored for over a year. The amplifier runs on a 400 Volts AC input and supports a connected load of 2.5 kVA for continuous operation. It delivers a continuous current of 4.2 Amps, with peak output reaching 8.4 Amps. Weighing just 2.1 kilograms and featuring compact dimensions (275 x 71 x 235mm), this IP20 rated amplifier promotes efficient space utilization.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Type

Digital Servo Amplifier

Compatibility

6SM Servo Motors

Package Contents

1 digifas 7200 Series Servo Amplifier, BS7200 Operator Software, 2 Ring Cores, Operating Manual

Transport Temperature Range

-25 to 70 degrees Celsius

Transport Humidity

not exceed 95%

Storage Temperature

-25 to 55 degrees Celsius

Cleaning Material

Isopropanol

Input

400 Volts AC

Rated Load

2.5 kVA

Continuous Output Current

4.2 Amps

Peak Output Current

8.4 Amps

Output Current Form Factor

1.01

Output Stage Clock Frequency

8.33 kHz

Residual Voltage Drop

5 Volts

Power Loss at Rated Current

60 Watts

Weight

2.1 kilograms

Dimensions

275 x 71 x 235 millimeters

Housing Rating

IP20

Operation Temperature Range

45 to 55 degrees Celsius (output derating)

Operation Altitude Range

1000 to 2500 meters (output derating)
