R911253702
The R911253702 (DKS01.1-W100A-DL04-00) is a premier servo drive produced by Bosch Rexroth Indramat. This unique Indramat servo drive controls and efficiently monitors crucial parameters such as power output, speed, motion, and torque of the MDD AC servo motor. It amplifies electrical signals sourced from the control center based on its software module's values. The drive subsequently transmits the equivalent current to the servo motor. The apparatus also includes an integrated braking mechanism, which can halt the current flow to the servo motor in critical situations. The R911253702 (DKS01.1-W100A-DL04-00) possesses a customizable error reaction which is implemented in case of any system malfunction. Its precision, durability and performance make it highly suited for diverse industrial applications including, but not limited to, CNC machinings, industrial automation, and robotics.
The R911253702 (DKS01.1-W100A-DL04-00) servo drive offers a seamless connection to the mains power through a three-phase electrical link. A motor feedback cable supports communication of digital signals with the MDD AC servo moto. The servo drive's electrical links are structured via screw terminals for uncomplicated maintenance and servicing. It accommodates adaptation to specific industrial needs via configuration components, which can be positioned into slots U1-U5 in the drive's casing. This servo drive carries a rated and peak current of 100 Amperes and a continuous current of 50 Amperes. It operates within 50 to 60 hertz power frequency range, requiring a rated power of 11 kilovolts Amperes at peak loading. The drive weighs approximately 11 kilograms.
30 Day Warranty
Technical Specifications
