S image of DSA 007-230-S

DSA 007-230-S

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The DSA 007-230-S, a product by Kollmorgen, belongs to their DSA digital servo drives series. It's a standard-sized, versatile unit, weighing 1.8 kgs, with a maximum power loss of 48 Watts, and an I/O response time of 100 microseconds. Designed for brushless motors with sinusoidal AC control, the unit can be remotely commissioned via DSAPro software. It operates on a single-phase AC input voltage ranging from 100 V to 240 V, with an AC input frequency of 47 Hz to 63 Hz. Its peak output current is 7.5 A, and the continuous output current is 2.5 A. With allowances for easy cable exchange, the unit has an energy absorption capability of 125 Joules at 115 Volts AC input, dropping to 51 Joules at 230 Volts. It has a continuous power output range of 0.25 kW to 0.5 kW. Its functioning in temperatures between 0o C and 55o C and relative humidity between 5% to 95% ensure optimal operation. In storage, the acceptable temperature ranges from -40o C to 70o C.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Line

DSA Digital Servo Drives

Product Number

DSA 007-230-S

Weight

1.8 kg

Maximum Power Loss

48 Watts

I/O response time

100 microseconds

Motor Type

Brushless motors with sinusoidal AC control

Input Voltage

Single-phase AC between 100 V and 240 V

AC Input Frequency Range

47 Hz to 63 Hz

Peak Output Current

7.5 A

Continuous Output Current

2.5 A

Energy Absorption at 115V

125 Joules

Energy Absorption at 230V

51 Joules

Continuous Power Output at 115V

0.25 kW

Continuous Power Output at 230V

0.5 kW

Memory Type

Flash memory

Short Circuit Protection

Phase-to-phase and phase-to-ground

Operating Temperature Range

0o C to 55o C

Relative Humidity Range

5 % to 95 % non-condensing

Storage Temperature Range

-40o C to 70o C.
