S image of DSA 046-460-S

DSA 046-460-S

by Kollmorgen
$2,362.50 - $2,362.50
$2,362.50
$2,362.50 - $2,362.50
$2,362.50

In Stock, Ships 1 - 3 Days

The Kollmorgen DSA 046-460-S is a high-tech digital servo drive crafted for optimum performance. This drive can be conveniently configured offline via the DSAPro software, a Windows-based application. The product comes without a user manual, but one can be added to your order free of charge. The drive's physical dimensions are 360.7 mm in height, 151.6 mm in width, and 242.4 mm in depth. It operates on a three-phase input voltage range of 230 to 480 Volts AC. Its auxiliary AC input current specs vary based on voltage, while its main AC input current stands at 14 A at 460 Volts AC, with a maximum inrush current of 6 Amps. The drive yields a continual output current of 23 Amps and an intermittent output current of 46 Amps. In addition, it touts internal and external shunt capabilities, with power ranges from 200 Watts to 16 kilowatts. Its continuous power ratings are 5 kilowatts at 230 Volts AC, and 10 kilowatts at 460 Volts AC.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product

DSA 046-460-S Digital Servo Drive

Software

DSAPro

Dimensions (HxWxD)

360.7mm x 151.6mm x 242.4mm

Input Voltage Rating

Three-Phase 230 to 480 Volts AC

Auxiliary AC Input Current (230 Volts AC)

0.55 Amps nominal

Auxiliary AC Input Current (360 Volts AC)

0.35 Amps nominal

Auxiliary AC Input Current (480 Volts AC)

0.25 Amps nominal

Main AC Input Current (460 Volts AC)

14 A nominal

Maximum Inrush Current (460 Volts AC)

6 Amps

Rated Continuous Output Current

23 Amps

Rated Intermittent Output Current

46 Amps

Internal Shunt Continuous Rating

200 Watts

Internal Shunt Peak Rating

16 kilowatts

External Shunt Continuous Rating

10 kilowatts

External Shunt Peak Rating

16 kilowatts

External Shunt Minimum Resistance

40 Ohms

Continuous Power Rating (230 Volts AC)

5 kilowatts

Continuous Power Rating (460 Volts AC)

10 kilowatts

Absorbed Power (230 Volts AC, 230 Volts Motor)

88 Joules

Absorbed Power (230 Volts AC, 460 Volts Motor)

776 Joules
