S image of DSM007

DSM007

by Kollmorgen
$672.65 - $672.65
$672.65
$672.65 - $672.65
$672.65

In Stock, Ships 1 - 3 Days

The Kollmorgen DSM007 is a compact micro-DSM series industrial drive, packing exceptional power into a small package. Delivering a peak current output of 7.5 amps and a continuous current output of 2.5 amps, it runs on an input voltage range of 100 to 240 Volts AC, with a frequency of 47 to 63 Hertz. Featuring ±10 Volts analog velocity input and digital serial commands, the DSM007 can operate up to 32 devices via its dual RS-232 and RS-485 serial ports, which support varying baud rates from 1200 to 19200. The drive incorporates high-performing control loops for torque, velocity, and position, all digitally managed with strong 300 Hertz velocity loop bandwidth. Moreover, incremental encoder enables motor feedback. With a robust design prepared for -5 to 55 degrees Celsius operating temperature, this lightweight 1.68 Kg drive is diligently constructed for efficient performance in challenging environments.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Series

Micro-DSM Series Drive

Model Number

DSM007

Peak Current Output

7.5 Amps

Continuous Output Current

2.5 Amps

Continuous Output Power Rating

0.5 Kilowatts

Continuous Shunt Power External

300 Watts

Peak Shunt Power

2.2 Kilowatts

Continuous Input Current

5 Amps

Input Voltage Range

100 to 240 Volts AC

Minimum Input Frequency

47 Hertz

Maximum Input Frequency

63 Hertz

Analog Velocity Input

±10 Volts

Presets

8

Serial Capability

RS-232 and Four-wire RS-485

Baud Rate

1200 to 19200 Baud

Number of Addressable Units

32

Control Systems

Torque, Velocity, Position

Control Loop Bandwidth

Max 300 Hertz

Interface Connectors

9-pin D-shell, 20 and 50 pin Mini D

Feedback

Incremental Encoder

Power Interface

Screw Terminal Block

Storage Temperature

-40 to 70 degrees Celsius

Operating Temperature

-5 to 55 degrees Celsius

Max Altitude

1500 Meters

Weight

1.68 Kilograms
