M.1300.5142
by Kollmorgen
Original price
$3,307.50
-
Original price
$3,307.50
Original price
$3,307.50
$3,307.50
-
$3,307.50
Current price
$3,307.50
Produced by Kollmorgen, the M.1300.5142 (DSA 030-230-S) is a high-performance digital servo drive from the DSA Series. Boasting an AC voltage rating of 230 Volts, it operates within an AC input range of 100 to 240 Volts (single-phase) and an input frequency between 47 to 63 Hertz. It draws a nominal AC input current of 18 Amps, with a maximum inrush of 100 Amps at 230 Volts AC. The servo drive delivers a peak output current of 30 Amps and a continuous output of 10 Amps. It packs an impressive energy absorption capability conceding 125 Joules at 115 Volts AC and 51 Joules at 230 Volts AC. Its power outputs are 1 kilowatt at 115 Volt AC and 2 kilowatts at 230 Volts AC. Weighing approximately 2.1 kilograms, the unit is operational within 0-55 degrees Celsius.
The M.1300.5142 (DSA 030-230-S) servo drive is designed to be stored in a temperature range of -40 to 70 degrees Celsius with an advised ambient relative humidity of 5 to 95%. The installation site's altitude should not surpass 1500 meters; any increase beyond 1500 meters requires a power output derate of 3% for every 300-meter rise. The heat dissipation stands at a maximum of 50 Watts in addition to the power lost through the dissipative shunt. Notably, the M.1300.5142 (DSA 030-230-S) possesses 3-phase sinusoidal commutation and various digital PI/PID regulators with differing update rates. The included integrated RS-232/RS-422/RS-485 serial port enhances its usability.
