M.1301.8656
by Kollmorgen
Original price
$1,925.20
-
Original price
$1,925.20
Original price
$1,925.20
$1,925.20
-
$1,925.20
Current price
$1,925.20
The M.1301.8656 (DSA 022-460-S), a high-performance servo amplifier, is a versatile creation of Kollmorgen, offering excellent results across multiple configurations - including use in variable speed drives and as a stepper drive substitute. This model from Kollmorgen's DSA series is expertly designed to operate brushless motors quietly and efficiently, thanks to advanced control methods. Providing flexibility across the board, this standard-sized 8.55 kg amplifier promises seamless operation and efficient output.
The M.1301.8656 (DSA 022-460-S) operates within a nominal voltage range of 230 V to 480 V, supported by an input frequency of 47 Hz to 63 Hz. Its internal and external shunts cater to a wide range of continuous and peak powers, with a continuous output current of 11A and an intermittent output of 22 A. Also notable are its I/O response time of 100 μsec and a firmware scan period of 1ms. The servo amplifier comes with a SERCOS interface and can function as a slave device in a ring that accommodates up to 32 axes, facilitated by fiber optics for quick communication. It can be controlled through the Windows-compatible DSAPro software tool from Kollmorgen and possesses a personality module that holds its setup parameters for easy transfer to a replacement unit, should the need arise.
