P image of EK1122-0080

EK1122-0080

by Beckhoff
$646.00 - $646.00
$646.00
$646.00 - $646.00
$646.00

In Stock, Ships Fast

The EK1122-0080, a product of Beckhoff's innovative approach to automation technology, is part of the EK1122 series of highly reliable, maintainable, and durable 2-port EtherCAT junctions. Designed to facilitate the formation of EtherCAT star topology configurations, the EK1122-0080 stands out for its 'Hot Connect' feature, which bolsters operational efficiency by facilitating changes to topologies and expediting the integration of the connected EtherCAT component into data communication. Also noteworthy is the 'Fast-Hot Connect' technology that curtails connection times and accelerates tool changes by leveraging specially labeled Fast Hot-Connect ports. Powered by E-bus and comes with two RJ45 bus connections, the EK1122-0080 must be mounted on a 35 mm rail adhering to EN 60715. At a weight of 70 grams, it operates optimally below 85˚C, possesses an IP 20 protection rating and CE, cULus, and ATEX certifications, and conforms to vibration and shock resistance standards set by EN 60068-2-6 and EN 60068-2-27 respectively. Unused ports should be fitted with blind plugs to deter dust accumulation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff

Product

EK1122-0080

Product Series

EK1122

Ports

2-port EtherCAT junction

Topology

Enables EtherCAT star topology

Hot Connect Feature

Yes

Fast-Hot Connect Technology

Yes

Connections

Two RJ45 bus

Power Supply

E-Bus

Weight

70 grams

Operating Temperature

Below 85˚C

Mounting

35 mm mounting rail (EN 60715)

Vibration

Conforms to EN 60068-2-6

Shock Resistance

Conforms to EN 60068-2-27

Approvals

CE, cULus, ATEX

Protection Rating

IP 20
