HCS01.1E-W0003-A-02-E-S3-EC-NN-L3-NN-FW

The HCS01.1E-W0003-A-02-E-S3-EC-NN-L3-NN-FW from Bosch Rexroth Indramat is part of the HCS IndraDrive Controllers series and represents the compact end of the HCS Drive Controller line. This Line Series HCS01 device is classified as a Product Type HCS Drive Controller designed for three-phase mains applications, accepting Mains Voltage 3 x AC 110...230 V ±10% to deliver precise drive control. Rated for a Device Peak Current 3 A output, it ensures adequate headroom for dynamic motor loads. The controller employs an IP Rating IP20 enclosure and features an integrated blower for Cooling Method Air, internal (through integrated blower), supporting natural convection within control cabinets. Built on Design Version 1, the HCS01.1E-W0003-A-02-E-S3-EC-NN-L3-NN-FW leverages a modular architecture that accommodates optional hardware expansions.

Performance is anchored by high-speed communication and robust safety integration. The unit provides a Communication Interface SERCOS III backbone, enabling real-time data exchange with compatible master controllers over SERCOS/EtherCAT protocols. A dedicated Safety Interface STO (Safe Torque Off) module prevents unintended motor torque generation by interrupting the drive output stage. Encoder connectivity is handled via Interface 1 Type Encoder IndraDyn Hiperface/EnDat 2.1/2.2, while Interface 2 Type Not equipped remains available for future extensions. Pairing is simplified through the integrated Pairing Note Paired with Control Section Design 'ECONOMY' (E), which aligns firmware and hardware configurations for optimized drive behavior. All control section functions rely on a Control Section Design Type ECONOMY platform, balancing cost and functionality for standard industrial automation tasks.

Installation and maintenance protocols emphasize system integrity and serviceability. The drive requires a Power Supply Unit Infeeding / Feeded arrangement, including a separate 24 V DC control voltage input with a maximum inrush of 3.3 A and a 2 ms pulse width to stabilize logic circuits. Firmware updates must follow the Firmware Order Note Firmware must be ordered as separate sub position process, with identification via type plates on both the control panel and the drive housing. Optional modules install seamlessly into the controller’s backplane, although Other Design Features None indicates no additional features are pre-installed. Only trained personnel should perform configuration and commissioning in compliance with all safety instructions to ensure reliable operation in applications such as machine tools, packaging lines, and automated assembly cells.
