HDS04.2-W200N-HS09-01-FW

Original price $5,522.02 - Original price $5,522.02
Original price
$5,522.02
$5,522.02 - $5,522.02
Current price $5,522.02
In Stock, Ships 3 - 5 Days
The HDS04.2-W200N-HS09-01-FW is a 2nd generation drive controller, developed by Bosch Rexroth Indramat. This part of the HDS series is marked out by being robust, long-lasting, and reliable with superior performance. This specific variant is a 4-line controller featuring a built-in fan that allows it to run optimally without overheating. Rated at 200 A, it belongs to the DIAX04 controller family with a SERCOS interface and the function ID code is 01. The firmware must be purchased separately. Features of this controller include a command communication module, software module, configuration type plate, and optional plug-in modules. The software module retains the drive parameters, allowing functionality to be easily transferred if a replacement is required. An additional ARCNET coupler plug-in card can be added for use with the CLC-D control card. The permissible operating temperature ranges from 5°C to 45°C, with a maximum of 55°C with de-rated data.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Servo Drive Controller
  • Model Number: HDS04.2-W200N-HS09-01-FW
  • Generation: 2nd
  • Product Family: HDS
  • Details: 4-line 2nd version controller with built-in fan
  • Current Rating: 200 A
  • Controller Family: DIAX04
  • Interface: SERCOS
  • Function ID Code: 01
  • Firmware: Purchased separately
  • Components: Drive controller, software module, command communication module, configuration type plate, additional plug-in modules
  • Operating Temperature: 5°C to 45°C (rated), max. 55°C (de-rated)
