BH-226-C-63-B3E106

The Kollmorgen BH-226-C-63-B3E106 servomotor is a precision synchronous drive engineered by Kollmorgen as part of the Kollmorgen Goldline B and BH Motors series to meet demanding automation requirements. This low inertia design delivers a Max Rated Power of 2.2 kW while sustaining a Max Speed of 7000 RPM, supporting rapid acceleration profiles in compact installations. The motor’s electrical bus operates at a Max BUS of 565/680, enabling high dynamic response and efficient energy utilization. Featuring a robust construction and brushless architecture, the BH-226-C-63-B3E106 ensures reliable operation in continuous and intermittent duty cycles across industrial applications. Integrated resolver feedback maintains precise position control, facilitating accurate motion sequences in high-performance systems.

Technical specifications of the BH-226-C-63-B3E106 highlight its versatility and resilience under varying load conditions. The unit provides a Standstill Torque of 5.5 Nm and a corresponding Standstill Current Rating of 4.4 A, ensuring stable holding capabilities at zero speed. Its electrical windings are rated for a Voltage of 400 V and operate optimally at a Rated Speed of 4000 min^-1 under nominal conditions. The rotor incorporates Pole Pairs: 2 for smooth torque generation, while the assembly supports a Max Stall Torque of 49.6 lb-in and a Max Peak Torque of 178.8 lb-in for short-duration overloads. An integrated thermal contact monitors winding temperature and the motor surface can reach a Max Surface Temperature of 100°C during heavy operation.

Operational features of the BH-226-C-63-B3E106 underscore its performance in closed-loop systems. When paired with the S606 SERVOSTAR 600 digital servo amplifier, the combination forms a precise torque or speed-control loop that reacts swiftly to control signals. The brushless configuration eliminates commutator-related maintenance, while the low rotor inertia supports rapid directional changes without sacrificing stability. Rugged resolver feedback ensures immunity to electrical noise and accurate position feedback, even in harsh environments. Certified as UL Recognized and CE Compliant, this motor offers dependable thermal management through its integrated winding contact and robust mechanical bearings.

System integration is streamlined via standardized connectors and earth grounding requirements, minimizing installation complexity and ensuring electromagnetic compatibility. The BH-226-C-63-B3E106 excels in precision positioning tasks within robotics, packaging machinery, and CNC equipment due to its dynamic torque response and compact footprint. Service personnel should observe proper cable routing—maintaining at least 20 cm separation between control and power lines—and utilize frictionally-locking, backlash-free couplings to protect against axial loads. Backed by a one-year warranty and global shipping support, this servomotor is tailored for engineers seeking high-performance motion solutions in advanced automation systems.
