P image of KSM01.2B-076C-35N-M1-HP0-SE-NN-D7-NN-FW

KSM01.2B-076C-35N-M1-HP0-SE-NN-D7-NN-FW

by Bosch Rexroth Indramat
$13,800.00 - $13,800.00
$13,800.00
$13,800.00 - $13,800.00
$13,800.00

In Stock, Ships 1 - 3 Days

The KSM01.2B-076C-35N-M1-HP0-SE-NN-D7-NN-FW is a distributed servo drive by Bosch Rexroth Indramat, featuring a servo motor and control sections encased in an IP 65 class protection housing. With a maximum speed of 4700 RPM and a rotor inertia of 0.00430 kg m2, the motor operates with an EN 60034-1 insulation class of 155. Its torque constant at 20 degrees Celsius is 1.85 Nm/A, and the voltage constant is 113.8 V/1000 RPM. The power section's specifications include a control voltage input of 30 to 42 Volts DC and consumption of 16.6 Watts, operated at 1240 Watts power rating. This 14.5-kilogram drive’s cooling mechanism utilises natural convection, and communicates through SERCOS 2 (RS-422). Although it lacks a holding brake, the option is available, and the feedback is handled by a built-in optical encoder. It functions optimally at ambient temperatures of 0 to 40 degrees Celsius.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Distributed Servo Drive

Protection Class

IP 65

Insulation Class

155

Maximum Speed

4700 RPM

Rotor Inertia

0.00430 kg m2

Thermal Time Constant

25 minutes

Torque Constant

1.85 Nm/A

Voltage Constant

113.8 V/1000 RPM

Maximum Current Rating

17.7 Amps

Maximum Torque Rating

20 Nm

Continuous Torque

8.7 Nm

Shaft Keyway

DIN 6885-1

Shaft Sealing Ring

Included

Power Section Rated Power

1240 Watts

Power Dissipation

165 Watts

Control Voltage Input

30 to 42 Volts DC

Power Consumption

16.6 Watts

Connection Voltage

750 Volts DC

Weight

14.5 Kilograms

Ambient Temperature

0 to 40 Degrees Celsius

Cooling Method

Natural Convection

Motor Feedback

Optical Encoder, Multiturn Absolute Hiperface with 128 increments

Holding Brake

Unavailable

Master Communication

SERCOS 2 (RS-422)
