R911382874
The R911382874 (KSM02.1B-071C-24N-S1-HG0-ET-SD-D7-NN-FW), a motor-integrated servo drive by Bosch Rexroth Indramat, requires 750 Volt DC input for functionality and offers standard features such as Hiperface single-turn 128 signal periods optical encoder, safe motion (with SBC), multiple Ethernet communication, and hybrid electrical connectors. Distinguished optional additions comprise of a 24 Volt DC holding brake with electric release and communication output coupling. The main motor shaft houses a sealing ring, providing it with protection from dust, water, and prevents oil leakage. The product uses natural convection for its cooling requirements.
The R911382874 (KSM02.1B-071C-24N-S1-HG0-ET-SD-D7-NN-FW) offers an impressive IP65 environmental protection rating, denoting the drive's dust-tight enclosure and its ability to resist low-pressure water jets. This superior protection permits drive installation near the operational machinery, thus saving space, as cabinets aren't required for drive mounting. The integrated servo motor can provide 10.5 Nm continuous torque, 35 Nm maximum torque, and a peak speed of 3400 RPM. The drive can bear a maximum axial force of 40 N. The system should only be installed when de-energized and disconnected electrically. Using adequate lifting gear and observing safety instructions is essential during transport and installation, ensuring optimal performance throughout its operational tenure.
