series image of MIV0204A-1-B5

MIV0204A-1-B5

by Okuma
$6,465.71 - $6,465.71
$6,465.71
$6,465.71 - $6,465.71
$6,465.71
Available, Shipping Varies
Okuma's product MIV0204A-1-B5 is a dual-axis servo drive unit within their motion control system. This MIV inverter is typically used for driving spindle/axis drive motors, and is equipped with a specialized integrated control board named ICB1, designed for motor command. Operating with a power supply unit of 300 Volts and 24 Volts DC, it is compatible with BL and PREX motors from Okuma. The control ROM type is 5. It has a 2 kW L-side unit capacity and a 4 kW M-side unit capacity. The unit contains a large-capacitance capacitor, weighs 7.8 kg and measures 380 mm × 100 mm × 325 mm. An informative seven-segment LED on the front panel indicates the operating status, with unique alarms and error codes for easy identification of issues. Before replacement, it is recommended to properly shut down the unit, allowing the charge indicator to be off for at least two minutes. The software and control board of the new unit should match the previous one to ensure safety.
30 Day Warranty
Technical Specifications
  • Manufacturer: Okuma
  • Product: MIV Inverter Dual-Axis Servo Drive Unit MIV0204A-1-B5
  • Voltages: 300 Volts, 24 Volts (DC)
  • Compatible Motors: BL motors, PREX motors
  • ROM Type: 5
  • L-side Unit Capacity: 2 kW (2.67 hP)
  • M-side Unit Capacity: 4 kW (5.36 hP)
  • Weight: 7.8 kg (17.2 lb)
  • External Dimensions: 380 mm × 100 mm × 325 mm
  • Status Indicator: 7-segment LED
  • Error Detection: Alarm System.
