P image of MSM030C-0300-NN-M0-CC1

MSM030C-0300-NN-M0-CC1

by Bosch Rexroth Indramat
$7,922.35 - $7,922.35
$7,922.35
$7,922.35 - $7,922.35
$7,922.35

Available, Shipping Varies

The Bosch Rexroth MSM030C-0300-NN-M0-CC1 belongs to the MSM series of motors, known for their high reliability, versatile installation, impressive overload capacity, and swift dynamics. This model offers options such as a holding brake, a shaft with a key, and an absolute encoder. Characterized by four pole pairs, the motor possesses a winding inductance of 17 millihenries and resistance of 4.3 Ohms. It showcases a voltage constant of 32.6 Volts/1000 RPM and torque constant of 0.54 Nm/Amp, at 20 degrees Celsius. Peak and continuous current ratings stand at 7.4 Amps and 2.3 Amps, respectively. The model's cooling process relies on natural convection, avoiding the need for a blower. The motor integrates an absolute encoder with 512 increments and uses a cable tail electrical connection. It has an electrical release holding brake with a 1.27 Nm torque rating, a 3000 RPM rated speed, and a maximum rotor speed of 5000 RPM. The motor, with dimensions 60mm x 60mm x 171.5mm, has a DIN 6885 shaft, an IP65-protected, unpainted housing and withstands temperatures of around 40 degrees Celsius.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Series

MSM

Motor Model

MSM030C-0300-NN-M0-CC1

Number of Pole Pairs

4

Winding Inductance

17 millihenry

Winding Resistance

4.3 Ohms

Voltage Constant

32.6 Volts/1000 RPM

Torque Constant

0.54 Nm/Amp

Peak Current Rating

7.4 Amps

Continuous Current at Standstill

2.3 Amps

Size/Length/Winding Code

030/C/0300

Cooling

Natural Convection

Encoder Type

Absolute Encoder with 512 increments

Electrical Connection

Cable Tail Type

Minimum Strand Cross Section for Cable

0.75 mm2

Shaft

With Key per DIN 6885

Holding Brake

Electrical Release rated for 1.27 Nm Torque

Rated Motor Speed

3000 RPM

Max Rotor Speed

5000 RPM

Dimensions

60mm Height, 60mm Width, 171.5mm Length

Housing

Unpainted with IP65 Protection Rating.
