S image of MT1502A2-R1C1

MT1502A2-R1C1

by Kollmorgen
$599.97 - $599.97
$599.97
$599.97 - $599.97
$599.97

In Stock, Ships Fast

The MT1502A2-R1C1 servo motor from Kollmorgen’s MTC Servo Motors series delivers high-precision performance. It features IP65 ingress protection, operates at 230V Vrms L/L, and reaches speeds up to 2400 RPM. The motor offers a stall continuous current of 2.6 A RMS with 3.3 Nm continuous torque and a stall peak torque of 10.0 Nm at 40 °C. Right-angle rotatable connectors and a 1-speed resolver enable flexible installation and reliable feedback.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Back EMF Constant (KB)

81.6 V/KRPM

Class

F

Connector Orientation


Right-angle, rotatable connectors

Feedback Device

1-Speed Resolver

Ingress Protection (IP)

IP65

Resistance (L/L @ 25 degrees C)

11.1 ?

Speed Rating

2400 RPM Max

Stack Length


Short

Stall Continuous Current

2.6 Amps (RMS)

Stall Continuous Torque

3.3 Nm @ 40 degrees C Ambient

Stall Peak Current

10.4 Amps (RMS)

Stall Peak Torque

10.0 Nm @ 40 degrees C Ambient

Static Friction


0.035 Nm

Voltage

230V Vrms L/L

Winding


Type A
