MTC506C1-R1A1-013

The MTC506C1-R1A1-013 is a high-performance servo motor engineered by Kollmorgen within the MTC Servo Motors series, offering precise motion control for demanding applications. This compact unit operates on a 24 VDC input voltage and draws a nominal 0.30 ADC input current, providing energy-efficient performance. With a static holding torque of 19.5 N-m and a maximum speed of 6000 RPM, the motor delivers a blend of power density and dynamic response. The unit features a low rotor inertia of 0.00010 lb-ft-s^2, enhancing acceleration and deceleration performance while minimizing overshoot. A robust 130 mm frame length and extended stack length ensure compatibility with a wide range of drive systems, including Kollmorgen's own Servostar series.

Technical excellence is built into every aspect of the MTC506C1-R1A1-013. The integrated single-speed resolver delivers high-resolution feedback for closed-loop position and velocity control, ensuring repeatability within micromechanical tolerances. An electrically releasing holding brake rated at 24 VDC maintains static loads securely when power is removed, enhancing safety and precision. The motor’s windings and rotor assembly are optimized for continuous operation at high speeds, while the minimal rotor inertia facilitates rapid torque changes. The combination of resolver feedback, low inertia, and precise torque production makes this motor ideally suited for high-acceleration indexing, pick-and-place, and robotic articulation tasks.

Operational reliability is assured by the IP65 housing and shaft seal, which protect against dust ingress and water jets, extending bearing life and preventing contamination of internal components. A sealed label plate on the housing provides quick reference to model number, torque and current ratings, input voltage, and protection class, facilitating maintenance and spare-parts ordering. The motor’s temperature resilience is enhanced by its robust design, enabling continuous duty cycles without derating under moderate ambient conditions. Installation and commissioning are streamlined when paired with Kollmorgen Servostar drives, which recognize the motor’s nameplate data automatically, reducing setup time and configuration errors.

Integration flexibility makes the MTC506C1-R1A1-013 an ideal choice for system designers. The motor is fully compatible with Kollmorgen’s Goldline 50 XT series of amplifiers and can be seamlessly incorporated into multi-axis architectures. Its combination of high torque density, low rotor inertia, and reliable feedback mechanisms supports applications in machine tending, CNC tooling, semiconductor handling, and automated assembly lines. When precise, high-speed motion control is required, the MTC506C1-R1A1-013 provides a robust, ready-to-deploy solution for optimizing throughput and maintaining tight process tolerances.
