S image of LSM100-35-454-E2-0KA

LSM100-35-454-E2-0KA

by Kollmorgen
$5,375.00 - $5,375.00
$5,375.00
$5,375.00 - $5,375.00
$5,375.00

In Stock, Ships 1 - 3 Days

The Kollmorgen LSM100-35-454-E2-0KA motor from the LSM Brushless Servo Motors series by Kollmorgen is an eight-pole brushless servo offering a peak torque of 16 Nm and a rated speed of 4500 rpm. It features a voltage constant of 103 V/kRPM, a torque constant of 0.86 Nm/A, and a maximum peak current of 22.6 A. Weighing 5.3 kg, the motor incorporates a durable ST-60 steel shaft and a rotor moment of inertia of 0.00017 kg·m². With a winding resistance of 5.9 Ω phase-to-phase and inductance of 16.8 mH, it delivers smooth, precise motion with reduced torque ripple, making it ideal for demanding industrial automation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Ke Voltage Constant (v/krpm)

103

Kt (nm/amp)

0.86

Maximum Current (amps Peak)

22.6

Motor Net Weight (kg)

5.3

Motor Net Weight (lb)

11.7

Peak Torque (in-lb)

142

Peak Torque (nm)

16

Poles

8

Rotor Moment Of Inertia (kg-m2)

0.00017

Rotor Moment Of Inertia (lb-in-s2)

0.0015

Shaft Material

ST-60

Speed (rpm)

4500

Stall Current (amps Peak)

5

Winding Inductance Phase To Phase (mh)

16.8

Winding Resistance Phase To Phase @ 25°c (ohm)

5.9
