S image of MTS-R01.2

MTS-R01.2

by Bosch Rexroth Indramat
$3,009.85 - $4,270.93
$4,270.93
$3,009.85 - $4,270.93
$4,270.93

In Stock, Ships 1 - 3 Days

The MTS-R01.2, manufactured by Bosch Rexroth Indramat, is an essential component of CNC controllers, integrating SPS and NC modules. Designed for versatile applications, it can operate efficiently in up to 75% humidity and be stored safely in up to 95% humidity without condensation. It is dust and dirt resistant, suitable for outdoor use, and supports optional INTERBUS and PROFIBUS-DP interfaces via U1-U3 slots. Its compact enclosure (83.7mm x 192mm x 156mm) weighs approximately 1 kg and is mountable on a TS 35 x 27 x 15 DIN rail. It operates under atmospheric pressure between 860-1080 hPa, up to 1500m altitude, and is transportable at 660-1080 hPa up to 3500m. The module requires a 24 VDC supply voltage (18-28 VDC permissible range), with up to 0.5 A current consumption and accepts a 1.5mm² power cable. It features a D-SUB, 15-way female connector for programming and serial interfaces, meeting DIN 40 040 class KV standards.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product

MTS-R01.2

CNC Controller Components

SPS and NC Modules

Humidity Safe During Operation

75%

Humidity Safe During Storage

95%

Moisture Condensation

None

Outdoor Application Safety

Dust and Dirt Resistant

Optional Slots

U1-U3

Field Bus Interfaces

INTERBUS and PROFIBUS-DP

Power Cable Cross-Section

Up to 1.5mm2

Mounting Racks

RMB02.2

DIN Rail

TS 35 x 27 x 15

Operating Atmospheric Pressure

860 to 1080 hPa

Maximum Operating Height

1500 meters

Transport Atmospheric Pressure Range

660 to 1080 hPa

Maximum Transport Elevation

3500 meters

Operating Temperature Range

0 to +50°C

DIN Standard Compliance

DIN 40 040 class KV

Dimensions

83.7mm x 192mm x 156mm

Mass

1 kg

Supply Voltage

24 VDC

Permissible Voltage Ripples

4 Vss

Voltage Range

18 to 28 VDC

Maximum Current Consumption

0.5 A

Programming Interface

D-SUB, 15-way female connectors

General-purpose Serial Interface

D-SUB, 15-way female connectors
