M image of M21NSXD-LNF-NS-02

M21NSXD-LNF-NS-02

by Pacific Scientific
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The M21NSXD-LNF-NS-02, produced by Pacific Scientific, is a 2-phase, 30W 76A DC stepper motor with a maximum operating speed of 1500 RPM. It consumes 1.51A current in parallel setup and 0.76A in series setup, with phase resistance of 10.5 ohms and phase inductance of 34.8 mH in parallel configuration. This versatile motor, encased in a 2.3” frame size, has standard NEMA mountings and can be installed with four screws. Equipped with an encoder mount and options for a 512 or 500 LPR encoder, the motor is ideal for applications that require precision movements. It features a maximum holding torque of 135 Nm when both phases are energised. The motor includes Sigmax® technology, minimising flux leakage for optimized torque. Its construction incorporates rare earth metals and an 8-pin electrical receptacle for power and feedback signal transmission, and functions effectively up to 40 degrees Celsius.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Pacific Scientific

Product Code

M21NSXD-LNF-NS-02

Type

2-phase, 30W 76A DC Stepper Motor

Maximum Speed

1500 revolutions per minute

Current Consumption parallel connections

1.51 amperes

Current Consumption series configuration

0.76 amperes

Phase resistance

10.5 ohms

Phase Inductance parallel configuration

34.8 mH

Mounting

Standard NEMA mounting flange

NEMA Size

23

Frame size

2.3 inches

Encoder

Mounting provision, can be equipped with 512 or 500 LPR encoder

Bearings

Larger-than-usual bearings

Applications

Complex motion applications

Power Supply and Feedback Signals

8-pin, integral electrical receptacle

Maximum holding torque

135 Nm with both phases energized

Product Series

POWERMAX II Hybrid Step Motors Series

Technology

Sigmax® technology

Materials used

Rare earth metals

Special Feature

Inhibits flux leakage

Shaft

one-sided, smooth shaft

Operating Temperature Limit

40 degrees Celsius.
