S image of SC452-011-05

SC452-011-05

by Pacific Scientific
$871.70 - $871.70
$871.70
$871.70 - $871.70
$871.70

In Stock, Ships 1 - 3 Days

The SC452-011-05 brushless servo controller, manufactured by Pacific Scientific under the renowned name of Kollmorgen, stands out thanks to its bespoke, high-quality construction. Designed for a diverse range of appliances, the product boasts field-replaceable brushes and constant force brush springs for enhanced durability. The SC452-011-05, weighing 2.7 kilograms, needs to operate within specific temperature and environmental parameters, namely a temperature range of 0 to 50 degrees Celsius at full rating and 10 to 90% humidity. The controller's peak output current measures 7.0 amps, with a stall current of 3.5 amps at 230 VAC or a standstill current of 4.2 amps at 115 VAC. Lastly, its output ripple frequency is 20 kHz and it features an adjustable velocity offset, as well as a shunt regulator with a peak power of 1500 Watts and a continuous power of 20 Watts.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Pacific Scientific

Brand

Kollmorgen

Product Code

SC452-011-05

Product Type

Programmable Brushless Servo Controller

Product Weight

2.7kgs

Operating Temperature (Full Ratings)

0 to 500C

Operating Temperature (Derating from 100% to 70%)

50 to 600C

Humidity(No condensation)

10 to 90%

Installation Peak Height

1500 meters above sea level

Storage Temperature

-55 to 700C

Nominal Bus Voltage (230 VAC Input)

320V

Nominal Bus Voltage (115 VAC Input)

160V

Maximum Peak Output Current

7.0 Amps

Continuous Input Current at Stall (230 VAC Input)

3.5 amps

Continuous Current at Standstill (115 VAC Input)

4.2 Amps

Output Ripple Frequency

20 kHz

Velocity Offset

Adjustable to zero

Shunt Regulator Peak Power (0.3s)

1500 Watts

Shunt Regulator Continuous Power

20 Watts
