R911289012
The R911289012 (PPC-R02.2N-N-N1-N2-NN-FW) is a robust CNC control unit produced by Bosch Rexroth Indramat, a distinguished manufacturer recognized for its reliable and durable motion control equipment. Primarily devised to manage numerous drives simultaneously, this control unit boasts a wide array of connectivity possibilities, including RS232, RS422, and RS485 serial interfaces.
The unit's design emphasizes usability and portability, reflected in its compact dimensions (83.7mm x 192mm x 150mm) and minimal weight (1.3kg). These features simplify its installation into a switch cabinet with RMB02.2 dual racks. The R911289012 (PPC-R02.2N-N-N1-N2-NN-FW) functions not only as an NC controller but as a standalone PLC system, and is fortified against foreign objects above 12.5mm. Its state-of-the-art diagnostics set-up communicates the system's status via the serial COM interface. Suited to a variety of industrial applications, the unit is powered by a lithium battery controlling the system clock and SRAM buffering. Depending on use, the SRAM can store varied data such as machine metrics, NC program or cycle packages, and NC variables. Storage is possible under tough industrial conditions, but preferential temperatures range from 0-45ᵒC and relative humidity levels from 10%-95% for best functioning.
30 Day Warranty
Technical Specifications
