M image of VAC-YMF22-18.5R-153KR2

VAC-YMF22-18.5R-153KR2

by Okuma
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The product at hand is the VAC-YMF22-18.5R-153KR2, a 3-phase AC spindle motor created by well-known Japanese manufacturer, Okuma. Part of the VAC series, this motor is designed for diverse factory automation tasks, facilitating the smooth running of operations. The motor operates optimally at an ambient temperature range of 0 to 40 degrees Celsius, with a maximum winding insulation temperature of 155 degrees Celsius, in compliance with NEMA's class F insulation requirements. It boasts a notable power output of 18.5 kW on a continuous basis, peaking at 22kW for 30 minutes, and can reach a top speed of 4,500 revolutions per minute. Integrated LEDs keep users informed of the motor's running status, aiding in timely diagnostic and troubleshooting processes. However, exposure to chips, oils, and water should be strictly avoided to ensure a long product lifespan. Finally, the motor should be used with authorized Okuma accessories, and the installation site should have a relative humidity not exceeding 95%, and be under 1000m above sea level.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Okuma

Product Line

VAC Series

Product Model

VAC-YMF22-18.5R-153KR2

Motor Type

3-Phase AC Spindle

Max Speed

4,500 RPM

Continuous Output Power

18.5 kW

Peak Power(30 mins)

22 kW

Number of Poles

4 Poles

Insulation Class

Class F

Operating Ambient Temperature

0°C to 40°C

Drive Unit

D22A/1104

Protection Against Chips/Oils/Water

Yes

Relative Humidity

Non-condensing, should not exceed 95%

Installation Altitude

Should not exceed 1000m above sea level.
