manufacturer image of VAM10.2-PB-NA-TA-TA-VB-1608-NN

VAM10.2-PB-NA-TA-TA-VB-1608-NN

by Bosch Rexroth Indramat
Request a quote
The Bosch Rexroth Indramat VAM10.2-PB-NA-TA-TA-VB-1608-NN is an operator panel intended for use with standard machine tools. The panel is equipped with 30 short-stroke keys, an authorization switch, and both emergency-OFF and ON/OFF buttons. It operates with an isolated power supply and has reverse voltage prevention. For residential usage, approval from a testing agency is needed. Installation should follow specified methods and it must not be used on certain machinery such as cranes and elevators. The panel uses a 3A SMD fuse, a one-pin key switch, and should be installed in conditions free from sunlight and potential interference. It is UL Listed, CSA certified, and requires Class 1 60/75°C wires. The operator panel features a 9-pin D-SUB female connector strip with a baud rate up to 12Mbauds. Shipping to requested addresses is available with proper packaging.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Machine operator panel
  • Product Code: VAM10.2-PB-NA-TA-TA-VB-1608-NN
  • Application: Standard machine tools or machine operator terminals
  • Number of Keys: 30 short-stroke keys
  • Additional Features: Key-operated authorization switch
  • Product Group: VAM
  • Power Supply: Electrically isolated
  • Additional Features: Reverse voltage protection
  • Buttons: Emergency-OFF button and an ON/OFF button
  • Line Code: 10
  • Application: Control tasks
  • Restrictions: Not for use in construction cranes and elevators
  • Current Consumption: 0.5A
  • Fuse: 3A SMD fuse
  • Key Switch: One pin and a forced opening contact
  • Certification: UL Listed and CSA Certified
  • Wire Type: Class 1 60/75°C °C wires
  • Installation Restrictions: Not for direct sunlight exposure
  • Interference Distance: Must be kept distant from interference sources
  • Key Design: Separated by separators
  • Interface: PROFIBUS DP field bus interface, 9-pin D-SUB female connector strip
  • Baud Rate: Up to 12Mbauds
