series image of VAM11.1-PB-NA-NN-TA-VB-1608-NN

VAM11.1-PB-NA-NN-TA-VB-1608-NN

by Bosch Rexroth Indramat
$1,310.01 - $1,310.01
$1,310.01
$1,310.01 - $1,310.01
$1,310.01
Available, Shipping Varies
The Bosch Rexroth Indramat VAM11.1-PB-NA-NN-TA-VB-1608-NN machine operator terminal is built for use in industrial settings, ideally with Bosch Rexroth's BTV 16 operator terminal. This compact device includes a programmable keypad with 15 illuminated keys and an E-STOP push button, plus a 4-stage key switch. It also offers multiple override rotary switches for spindle and feed functions. Other features include 8 digital 24V outputs, 16 digital 24V inputs, and both a 6-pin and 25-pin connector for additional component connections. The device is made from varnished aluminum covered with a chemically-resistant polyester foil in a light grey shade, and includes reverse voltage protection. The operator terminal is suitable for use in lathes, machining centers and milling machines but should be protected from direct sunlight and physical obstructions.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Code: VAM11.1-PB-NA-NN-TA-VB-1608-NN
  • Product Type: Machine Operator Terminal
  • Intended Use: BTV 16 Operator Terminal
  • Line Code: 11
  • Design Code: 1
  • Features: E-STOP Push Button, 15 Illuminated keypad keys, 4-stage key switch
  • Additional Features: Override Rotary Switches for Spindle and Feed
  • Mounting: 7 cutouts for 22.5mm indicator and control units
  • Rear Connections: 8 digital 24V outputs, 16 digital 24V inputs, 6-pin connector, 25-pin connector
  • Communication Bus Type: PROFIBUS-DP
  • Configuration Code: NA-NN-TA-VB
  • Applications: Lathes, Machining Centers, Milling Machines
  • Front Foil Color: RAL 7035 Light Gray
  • Front Foil Material: Varnished Aluminum with Chemical Resistant Polyester Foil
  • Power Supply: Electrically Isolated with Integrated Reverse Voltage Protection
  • Maximum Shock: 15 G
  • Permanent Maximum Vibration: 1.75mm amplitude at 5 to 9Hz
  • Shipping: Worldwide
