S image of VAM12.1-PB-NF-AB-TB-VD-EK-1608-D1

VAM12.1-PB-NF-AB-TB-VD-EK-1608-D1

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The Bosch Rexroth Indramat VAM12.1-PB-NF-AB-TB-VD-EK-1608-D1 is a sophisticated machine control panel designed for CNC machines, equipped with a PROFIBUS connection. Its features include four long-stroke buttons, nine assembly breakouts for switch elements, a 25-pin connector for handheld terminal connection, and 16 digital 24V inputs. This panel also houses a 6-pin connector for handwheel attachment. Importantly, the device supports the addition of sensors and actuators for refined monitoring and control. The robust front panel is crafted from anodized aluminum with a polyester foil. Despite its robust design, the device should not be exposed to extreme or fluctuating temperatures. Its operating temperature range lies between +5°C to +45°C. This UL Listed and CSA Certified panel consumes a maximum current of 1.7A, and bears DIN EN 50178 grade-1 protection. The panel features a VAC 30.2 connection module, an Override VD module, and can automatically identify bfd rates at the PROFIBUS DP.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product model

VAM12.1-PB-NF-AB-TB-VD-EK-1608-D1

Product type

Machine Control Panel

Button number

Four long-stroke buttons

Assembly Breakouts

Nine

Connection Type

25-pin connector

Digital Inputs

16 digital 24V inputs

Connector type

6-pin connector

Application

Manual operation of machines, CNC machines

Additional Actuator and Sensor connection

Yes

Installation Requirement

Should not expose to extreme temperatures or temperature variation

Protection Degree

1 according to DIN EN 50178

Front Panel Material

Anodized Aluminium with Polyester Foil

Current Consumption

Maximum 1.7A

Emergency Button Torque

0.8Nm

Operating Temperature

+5°C to +45°C

Certification

UL Listed, CSA Certified

Connection Module

VAC 30.2

Override Module

VD module

Keypad Arrangement

Matrix of five rows and three columns with green LED illumination

Design Code

1

Maintenance

Maintenance-free, not to be cleaned with solvents, steam jet or compressed air

PROFIBUS DP Connection

Automatically identifying the baud rate, supporting 10 baud rate.
