0811405106
Built by Bosch Rexroth Indramat, 0811405106 (VT-MSPA 2-525-10-V0) is a product that leverages combined global expertise for the development of innovative system components. These components include analog amplifier modules, digital axis controllers, brake choppers, valve controllers and drive controllers. The product is designed to propel industry advancements by providing custom solutions.
The specific model, 0811405106 (VT-MSPA 2-525-10-V0), features solenoid current analog output with a range of 0 to +/- 2.5 mA, and an impedance load minimum of 1000 ohms. It operates with a nominal voltage of 24 VDC and uses less than 2 A. The amplifier module is designed to produce a maximum current of 1 A with an adjustable clock frequency of 95 to 505 Hz. Certified under IP20, it can be mounted on top hat rails and uses three tension spring plug-in connections for electric linking. This model, weighing only 0.14 Kg, is designed to operate within 0 to +60°C. Its quick-start feature enables it to start in less than a second. However, 0811405106 (VT-MSPA 2-525-10-V0) module needs to be set up vertically with ample ventilation space and the model also includes a clock generator and a current controller. Storage should be within a temperature range of +5 to +40 degrees, with UV protection.
