0811405126
Bosch Rexroth Indramat is the producer of the 0811405126 (VT-MSPA 1-508-10-V0) model, an analog amplifier primarily used for operating pressure valves. Built with energy efficiency, longevity, and cost-effectiveness as a focal point, this module is ideal for a variety of industrial applications. It incorporates a standard top hat rail attachment for control cabinets, thanks to its modular design. A 24 VDC working voltage powers the unit, and it features a soldered electronic overload protection SMD fuse for added security. The model also houses a ramp generator with restricted control output increase and a 6-screw terminal connection.
The 0811405126 (VT-MSPA 1-508-10-V0) model comes with a characteristic curve generator that adjusts the command value signal to create a linear command value pressure characteristic curve. It has a differential command value input with a voltage range of 0 to +10 V and 100 Kohms resistance. The proximity of radios and other devices emitting electromagnetic waves should be maintained at a minimum of one meter. The unit's power and current consumption are less than 50 VA and 1.3 A respectively. This amplifier module must be de-energized before connecting to wires to ensure safe operation.
