0GH-D0480
The B&R Automation 0GH-D0480 is an advanced digital output module from 2005, designed for industrial environments. Featuring 16 transistor outputs at 24 VDC, it provides robust control with two electrically isolated output groups to prevent cross-talk and enhance safety. Each output handles a continuous current of 2 A, with group and module limits of 12 A and 24 A, respectively. It supports a switching frequency of up to 500 Hz for rapid performance and includes overload protection that resets after 1 second. The module's leakage current is low at 0.1 mA when off, and it manages short circuit currents up to 90 A. With a residual voltage of 0.3 V at 2 A and a braking voltage of 56 V, it ensures efficient operation. A separate TB170 terminal block is required. This single-width, C-UL-US listed module, identified by the B&R ID Code $41, is versatile and reliable for diverse automation applications.
