S image of 0GH-DO650

0GH-DO650

by B & R Automation
$1,341.59 - $1,341.59
$1,341.59
$1,341.59 - $1,341.59
$1,341.59

In Stock, Ships Fast

The 0GH-DO650, developed by B&R Industrial Automation in 2005, is a high-performance digital output module with 16 relay outputs supporting 120 VAC and 24 VDC inputs. Designed for industrial applications, it handles starting currents up to 12 A and is organized into four electrically isolated output groups for enhanced safety. Each relay supports a switching frequency of up to 10 Hz, with typical switching delays of 5.6 ms (Log. 0 to Log. 1) and 2.5 ms (Log. 1 to Log. 0). Power consumption is rated at a maximum of 0.7 W at 5 V, 3.3 W at 24 V, totaling 4 W. The module requires a separate TB170 terminal block for installation, while short circuit protection is externally provided via an 8 A time lag fuse per group. It accommodates a switching capacity from 0.1 mA/0.1 VDC to 300 VA/90 W and includes electrical isolation up to 144 VAC from output-to-PLC and 250 VAC from group-to-group.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

B & R Automation

Product

0GH-DO650

Type

Digital Output Module

Launch Year

2005

Relay Outputs

16

Input Voltage

120 VAC and 24 VDC

Starting Current per Relay

12 A

Output Groups

4 electrically isolated

Internal Voltage Limit

400 VSS

Contact Resistance at Full Load

100 mΩ

Switching Frequency

10 Hz

Power Consumption

0.7 W at 5 V; 3.3 W at 24 V; 4 W total maximum

Switching Delay Log. 0 to Log. 1

5.6 ms typical, 10 ms maximum

Switching Delay Log. 1 to Log. 0

2.5 ms typical, 5 ms maximum

Switching Capacity

0.1 mA / 0.1 VDC to 300 VA / 90 W

Electrical Isolation Output-to-PLC

144 VAC

Electrical Isolation Group-to-Group

250 VAC

Isolation Between Individual Outputs

None

Required Terminal Block

TB170 ordered separately

Short Circuit Protection

8 A time lag fuse per group

External Protective Circuit

Advised
