The Sanyo Denki 103-3609-02T1 is a high-precision incremental encoder in the High Accuracy Absolute Encoders series delivering 1000 pulses per revolution with 23-bit resolution. Featuring open collector/TTL output, it operates on 5-24V DC, mounts via flange or face, and offers IP54 environmental protection.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Cabling
Connector or cable options per manufacturer's documentation
Encoder Type
Incremental
Environmental Protection
IP54 or higher (typical)
Mounting Configuration
Flange or face-mounted
Operating Temperature
-20C to +70C
Output Type
Open collector/TTL
Reference Code
6128067
Resolution
23 bits
Shaft Diameter
6-12 mm (common range)
Signal Frequency
Several kHz
Supply Current
Less than 50 mA
Supply Voltage
5V-24V DC
Vibration Resistance
Up to 15G
Warranty
One-year
