104913773
The 104913773 (SD-B5.250.020-05.000), belonging to the Bosch Rexroth Indramat brand, is a brushless servo motor. It functions in conjunction with an SM..-T servo module and a power supply unit to form a modularly designed inverter system. The motor and the module are connected via terminals W2, U2, and V2 and plug-in connectors; the maximum permissible connector size is 2.5mm2. Optimum operation of the 104913773 (SD-B5.250.020-05.000) is achieved when tied with the SM 17/35-T model servo module, which actively governs the motor’s torque and speed.
The SM 17/35-T module carries an IP 00 protection level, can be installed up to a height of 1000m, and operates within a temperature range of 0 to 55 degrees, with storage ability from -25 to 70 degrees. With a power supply of 22W, its rated peak current and rated current are 460V and 17A respectively. Integral features include feedback systems and control inputs and outputs that contribute to accurate motor control. Optional modules like diagnostics, tandem drive, backlash compensation, short circuit braking, and a ramp generator are available. Monitoring functions for system errors, motor blockages, speed, and connection irregularities assure seamless operation and safety. For optimal performance, the servo motor and the module should be well-matched.
