1070170150
The 1070170150 (PPC-R22.1N-N-V2-NN-NN-FW), manufactured by Bosch Rexroth Indramat, is a sophisticated CNC module with an integrated axis and CNC processor system. It facilitates the connection of up to eight drives via a SERCOS interface. This Rexroth product offers three optional slots which could all fit an axis processor module. For optimum functionality, it should not be installed horizontally, as this may damage its components. Occupying two module slots in the module rack, the unit carries a weight of 1.3kg. Unique features include the S1 button that toggles the display, and a three-pin socket for buffer battery connection. Notably, the COM (X16) and PROG (X10) interfaces, as well as the X15 BT bus connection do not have a function.
Operating at 24VDC voltage rating, the 1070170150 (PPC-R22.1N-N-V2-NN-NN-FW) module conforms to EN61131-2 specification with a -15% / 20% tolerance and a maximum gain of 5%. Safeguarding SRAM data requires battery replacement while the power supply is running. The axis processor is a passive SERCOS interface in a PC/104 format, complemented by a boot loader/monitor feature crucial for hardware initialization and starting the CNC module. The device communicates with digital drives via a SERCOS interface with fiber optic technology and requires thorough manual review before installation or start-up. With a relative humidity of 10% to 95% without condensation, it can get considerably hot.
