2AI700.6
The B&R 2AI700.6 Analog Input Module, part of the B&R System 2010, delivers robust and adaptable solutions for industrial automation. It features a 12-bit resolution for precise data acquisition essential in industrial processes. Electrical isolation between input and PCC ensures safe operation, although individual inputs lack isolation. The module's conversion time is one millisecond, catering to time-sensitive applications. It operates at a load of 50.5 ohms, with a voltage drop of 1V at 20 mA and an input filter cutoff frequency of 400 Hz to improve signal integrity. Measurement accuracy is approximately 0.25% at 20°C and 0.375% between 0-60°C. The 2AI700.6 boasts a common mode rejection ratio (CMRR) that suppresses 50 Hz signals by up to 40 dB, enhancing noise immunity. Consuming up to nine watts, it is energy-efficient and compact, measuring 285 mm in height, 40 mm in width, and 185 mm in depth, ensuring smooth system integration.
