S image of 2DO428.6

2DO428.6

by B & R Automation
$1,024.05 - $5,663.64
$1,024.05
$1,024.05 - $5,663.64
$1,024.05
The B&R 2DO428.6 Digital Output Module is an advanced component designed for the B&R System 2010, launched in 2010. Engineered for efficient digital signal processing in industrial automation, it features 32 transistor outputs divided into four isolated groups to enhance safety and reduce disturbances. Operating at a nominal voltage of 24 VDC, each output supports a voltage range of 18 to 30 VDC, with a continuous current capacity of 0.5 A per output. Collectively, the unit can handle up to 16 A, with overload protection resetting in approximately five seconds. The module offers a logic switching speed of five microseconds from low to high and 60 microseconds from high to low, suitable for resistive loads up to 500 Hz. It includes features like internal overvoltage protection up to 55 V and reverse voltage protection, ensuring reliability and a long lifespan. Maximum power consumption is 5 watts internally and an additional 2 watts externally per group under a 24 V supply.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Product

B&R 2DO428.6 Digital Output Module

Manufacturer

B&R Automation

System Compatibility

B&R System 2010

Launch Year

2010

Number of Outputs

32 transistor outputs

Output Grouping

4 groups of 8 outputs each

Electrical Isolation

Isolation between groups, none within a group

Nominal Switching Voltage

24 VDC

Minimum Switching Voltage

18 VDC

Maximum Switching Voltage

30 VDC

Continuous Current per Output

0.5 A

Continuous Current per Group

4 A

Total Unit Current

16 A

Overload Protection Reset Time

5 seconds

Switching Time (0 to 1)

5 to 110 microseconds

Switching Time (1 to 0)

60 to 100 microseconds

Max Switching Frequency

500 Hz

Overvoltage Protection

55 VDC (VDE160)

Reverse Voltage Guard

45 to 55 VDC

Short-Circuit Current Range

0.75 to 1.5 A

Leakage Current (Off)

0.3 mA

Max Internal Power Consumption

5 W

Max External Power Consumption

2 W per group

Load Type

Resistive
