2DO430.6
The B&R 2DO430.6 Digital Output Module, part of the B&R System 2010, is a robust and versatile component designed for industrial automation. Featuring 32 transistor outputs split into four isolated groups of eight, it safely accommodates varying industrial applications. Each output operates at a nominal switching voltage of 24 VDC (range: 18-30 VDC) and supports a continuous current of up to 2 A per output or 12 A per group, with a total device capacity of 48 A. The system tolerates heavy-duty use, with leakage current kept below 1.5mA when switched off. Electrical isolation is maintained between groups, and the module allows for switching delays under 100 µs and frequencies up to 500 Hz. Overload protection, handling over-voltage up to 55V, and reverse voltage safeguards enhance reliability. Compactly sized at 285 x 40 x 185 mm and using only 2.9 watts, the module is energy-efficient and suitable for space-constrained environments.
