S image of 2DO710.6

2DO710.6

by B & R Automation
$585.00 - $585.00
$585.00
$585.00 - $585.00
$585.00

Available, Shipping Varies

The 2DO710.6 is part of the System 2010 Controllers series from B & R Automation, featuring 8 change-over and 8 normally open outputs with single-channel isolation. It operates at 30 VDC / 240 VAC with a rated current of 4 A and supports a maximum switching voltage of 125 VDC / 264 VAC. The controller handles switching power up to 2000 VA; 120 W @ 30 VDC, with contact resistance of max. 100 mΩ @ 6 VDC / 100 mA, and consumes internal max. 7 W, external max. 8 W, ensuring reliable industrial automation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Base Plate Module

BP200, BP201, BP210

Contact Resistance (dc)

Max. 100 mΩ @ 6 VDC / 100 mA

Maximum Switching Voltage

125 VDC / 264 VAC

Number And Type Of Outputs

8 change-over, 8 normally open

Power Consumption

Internal Max. 7 W, External Max. 8 W

Rated Current (resistive Load)

4 A

Rated Frequency

DC or 45 - 63 Hz

Rated Voltage

30 VDC / 240 VAC

Single Channel Isolation

Yes

Switching Power

2000 VA; 120 W @ 30 VDC (resistive load)

Switching Voltage Range

Min. 5 VDC @ 1 mA
